EL2-E monoblock for non-flammable chemicals in 5, 10 and 20 L jerrycans — Spain
| Customer | Chemicals producer |
| Country | Spain |
| Year | 2011 |
| Industry | Chemicals |
| Product | Non-flammable chemicals |
| Containers | 5, 10 and 20 L jerrycans |
| Machine | EL2-E, monoblock |
| Functions | One filling station · expandable to a second filling station and capping |
| Built | 2011 |
The challenge
A chemicals producer in Spain needed to fill three jerrycan sizes automatically, starting with a compact machine and keeping the option to grow.
The solution
EL2-E Monoblock to Fill Canisters from 1 to 30 Litres, Equipped with Only 1 Filling Station
An EL2-E monoblock with one filling station, prepared to add a second filling station and a capping station later.
The result
Three formats on one automatic machine since 2011, with the expansion already designed in.
How the EL2-E works
The EL2-E is a sequential machine. Jerrycans advance from station to station, and on each cycle all of them move one position, so operations happen in parallel on different containers. Each filling station has its own scale. In the horizontal version, positions that are not used are built ready for a later extension: adding a filling station or a capping station does not mean replacing the machine.
Built to grow
That is what this customer chose: one filling station to start with, and a frame ready for a second filling station and for capping. Three jerrycan sizes — 5, 10 and 20 litres — run on the same machine, with a filling recipe for each.
